Specification
| Model | CS-SEP-50W | CS-SEP-80W | CS-SEP-100W | CS-SEP-150W |
| Power | 50W | 80w | 100w | 150w |
| Luminous flux | 5000lm | 8000lm | 10000lm | 15000lm |
| Solar Panel Type | Polycrystalline Silicon | Polycrystalline Silicon | Polycrystalline Silicon | Polycrystalline Silicon |
| Color rendering index | Ra>80 | Ra>80 | Ra>80 | Ra>80 |
| Lamp size | 500*210*60mm | 620*260*80mm | 720*280*80mm | 860×320×80mm |
| Solar panel size | 400*350mm | 460*350 | 550*350mm | 510×430mm |
| Material | Dia-casting Aluminum | Dia-casting Aluminum | Dia-casting Aluminum | Dia-casting Aluminum |
| Solar panel | 6V/18W | 6V 22W | 6V 28W | 6V 35W |
| Battery | LiFePO4 Battery | LiFePO4 Battery | LiFePO4 Battery | LiFePO4 Battery |
| Working Temperature |
-20~+60℃ |
-20~+60℃ |
-20~+60℃ | -20~+60℃ |
| Battery Power | 3.2V 20AH | 3.2V 25AH | 3.2V 30AH | 3.2v 35Ah |
| Charging | 6-8h | 7-8h | 6-8h | 7-8h |
| Discharging Time | 8-12h | 8-12h | 8-12h | 8-12h |
| Time for rainy day | 3-5 day | 3-5 day | 3-5 days | 3-5 days |
| Install Height | 4-6m | 4-6m | 6-8m | 6-8m |
More details
1.Highlighted COB LED Chip
The light uses high level led chip which is energy saving and more steady.It’s with lower light decay,which is lower than 2%
glowing every 3000hours.This kind of led chip dissipates less heat when glows,so the light can be more durable and energy
saving.In addition,the light color is more clear with higher color rendering index. Good led chip is very important.More led
doesn't necessarily mean more bright.Choose good led.
2.Aluminum housing:
The light housing is refined,durable and hard.The housing is made of refined die-cast aluminum,which is anti-corrosion, impact
resistance,moisture-proof and waterproof, so it makes a long life of the light.The surface is refined carefully in polishing
process and paint process to avoid flaking paint and rust.Sealed extremely well and can prevent water,dust and all kinds of bad
weather like rain,hail and snow.
3.High Efficient Solar Panel
The solar panel is made of polycrystalline
silicon,which works more efficiently in weak light.The outer layer of the solar glass laminate is made of highly transparent
tempered glass,with transmittance as high as 93%.And the solar panel is well sealed,which can prevent all kinds of bad weather
like rain,hail and snow.
4.Lithium battery
The in-built lithium battery is of large-capacity and more sufficient to insure the light illuminate overnight. It’s also more
stable and safe for using with short circuit protection,input protection and over voltage protection. And the use of low discharge
technology greatly reduces the natural loss of electricity.
FAQ
Q1. CAN I HAVE A SAMPLE ORDER FOR LED LIGHT?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. WHAT ABOUT THE LEAD TIME?
A: Sample needs 1-5 days, bulk order production time needs 1-2 weeks
Q3. WHAT KIND OF CERTIFICATION DO YOU HAVE?
A: We have CE RoHS, CCC, ISO9001
Q4. HOW DO YOU SHIP THE GOODS AND HOW LONG DOES IT TAKE TO ARRIVE?
A:Small order would be ship by International Expresses (3-7 days) or International logistics parcel (15-20 days). Bulk order would be ship by Airline (5-7 days airport to airport) and sea shipping (20-40days port to port).
Q5. IS IT OK TO PRINT MY LOGO ON LED LIGHT PRODUCT？
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q6. HOW TO DEAL WITH THE FAULTY?
A:During the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
Customer's feedback
